Air flow meter Extractor

Gas flow meter Extractor

Brush

Multitool

Ceramic spray

Fume extraction torch
Light weight – only 1,1 kg
CO2 – 280 Amp
250 Amp Mixed gases
100% Duty cycle
Air cooled
Specifications

• Integrated extraction on the gas nozzle
• Lightest torch currently on the market – Only 1,1 kg
• Metal neck
• Flexible and maneuverable hose with ball-socket joint
• Small, ergonomic handle
• 90-95% fume extraction
• 3 interchangeable nozzles for various applications
• Especially designed for welding jobs where constant changing in positions is required, such as in automotive welding

Fume extraction welding torch gun with flexible hose

CO2 – 320 Amp

300 Amp Mixed gases

100% Duty cycle

Air cooled

Specifications

• Fume extraction at the source
• Extra flexible hose
• Ergonomic handle
• For heavy-duty applications
• 3 interchangeable nozzles for various applications
• 90-95% fume extraction
• 45° bent metal neck for sturdier look and feel on the job

• Fume extraction welding torch gun with flexible hose
• CO2 – 550 Amp
• 500 Amp Mixed gases
• 100% Duty Cycle
• Water cooled

Specifications

• Fume extraction at the source
• Extra flexible hose
• Ergonomic handle
• For heavy-duty applications
• 90-95% fume extraction
• 3 interchangeable nozzles for various applications
• 45° bent metal neck

8TE TIG EXTRACTOR – 17 – Air COOLED
DC – 140 AMP, AC/DC – 100 AMP, DUTY CYCLE – 35%

Specifications:
Reduces Welding Fume Up To 95%.
Same convenient handle as regular 8XT gun.
Various switch modules are available.
Extreme Flexible hose on the first meter.
Standard TIG consumables.

The 8TE TIG Extractors protect the welders and other workers in the factory from harmful fumes
and metals like Aluminium, Chromium, Iron, Manganese, and Nickel which are possibly released during the welding process.

8TE TIG EXTRACTOR – 30 – Water COOLED
DC – 320 AMP, AC/DC – 330 AMP, DUTY CYCLE – 100%

Specifications:
Reduces Welding Fume Up To 95%.
Same convenient handle as regular 8XT gun.
Various switch modules are available.
Extreme Flexible hose on the first meter.
Standard TIG consumables.

The 8TE TIG Extractors protect the welders and other workers in the factory from harmful fumes
and metals like Aluminium, Chromium, Iron, Manganese, and Nickel which are possibly released during the welding process.

8TE-35 TIG EXTRACTOR – Water Cooled
DC – 320 Amp, AC/DC – 230 AMP, DUTY CYCLE – 100%

Specifications:
Reduces Welding Fume Up To 95%.
Same convenient handle as a regular 8XT Torch.
Various switch modules are available.
Extreme Flexible hose on the first meter.
Standard TIG consumables.

The 8TE TIG Fume Extractors protect the welders and other workers in the factory from harmful fumes
and metals like Aluminium, Chromium, Iron, Manganese, and Nickel which are possibly released during the welding process.

8XE MINI MIG EXTRACTOR – AIR COOLED
CO2 – 280 AMP, MIXED GASES – 250 AMP, DUTY CYCLE – 100%

Specifications:
Reduces Welding Fume Up To 98%
Unique contact tip for manual fitting and durability.
Special design contact tip for longer lifetime.
Ergonomic ball socket 30° angle and 360° rotatable.
Two unique nozzle design 12mm and 14mm for optimal performance and durability

The 8XE MIG Extractor integrates the most efficient fume extraction structure in the welding industry.
The torch comes with three different angles, 30°, 45° and straight. The 8XE MIG Extractor, combined
with the ClearO2 W-series 100 and 200, captures up to 98% of welding fumes directly at the source.
The 8XE MIG Extractor provides the safest and most effective solution for welders and workers to
breathe CLEAN AIR and better work environments

8XE MIG EXTRACTOR – AIR COOLED
CO2 – 320 AMP, MIXED GASES – 300 AMP, DUTY CYCLE – 100%

Specifications:
Reduces Welding Fume Up To 98%
Unique contact tip for manual fitting and durability.
Special design contact tip for longer lifetime.
Ergonomic ball socket 30° angle and 360° rotatable.
Two unique nozzle design 14mm and 17mm for optimal performance and durability

The 8XE MIG Extractor integrates the most efficient fume extraction structure in the welding industry.
The torch comes with three different angles, 30°, 45° and straight. The 8XE MIG Extractor, combined
with the ClearO2 W-series 100 and 200, captures up to 98% of welding fumes directly at the source.
The 8XE MIG Extractor provides the safest and most effective solution for welders and workers to
breathe CLEAN AIR and better work environments

8XE MIG EXTRACTOR – Water COOLED
CO2 – 500 AMP, MIXED GASES – 500 AMP, DUTY CYCLE – 100%

Specifications:
Reduces Welding Fume Up To 98%
Unique contact tip for manual fitting and durability.
Special design contact tip for longer lifetime.
Ergonomic ball socket 30° angle and 360° rotatable.
Two unique nozzle design 14mm and 17mm for optimal performance and durability

The 8XE MIG Extractor integrates the most efficient fume extraction structure in the welding industry.
The torch comes with three different angles, 30°, 45° and straight. The 8XE MIG Extractor, combined
with the ClearO2 W-series 100 and 200, captures up to 98% of welding fumes directly at the source.
The 8XE MIG Extractor provides the safest and most effective solution for welders and workers to
breathe CLEAN AIR and better work environments

The ClearO2 unit is available with a power supply of 220V-240V (T100)  and CSA and CE certified. W3 Under construction.

Specifications

The ClearO2 T100 is designed to accompany the 8TE TIG Extractor from Translas. With the combination of the 8TE TIG Extractor range of welding fume torch and ClearO2 T100 unit we capture between 90% and 95% of welding fume at the source and filter these with efficiency > IFA 99.8%. The compact unit is perfect for changing location on the job due to its lightweight – only 30 kg – and its four wheels with two lockable.

Automatic Cleaning

The ClearO2 T100 unit has an automatic cleaning function by reverse compressed air pulse. The moment the under pressure in the filter is too high, the unit starts to clean the filter automatically. A manual cleaning function can be done by pressing a single button. The automatic Start/Stop function to preserve energy and to synchronize the unit with the 8TE TIG Extractor is a standard on the ClearO2 units. The moment the torch is out of the specially designed torch holder option, the machine automatically starts working.

Light and Mobile

The ClearO2 T100 unit is designed to serve the needs of a single welder, who needs to change their work-place.

The ClearO2 unit is available with a power supply of 220V-240V (T200) and CE and W3 certified.

Specifications

The ClearO2 T200 is designed to accompany the 8TE TIG Extractor from Translas. With the combination of the 8TE TIG Extractors range of welding fume torches and ClearO2 T200 unit we capture between 90% and 95% of welding fume at the source and filter these with efficiency > IFA 99.8%. The compact unit is perfect for changing location on the job due to its lightweight – only 45 kg – and its four wheels with two lockable.

Automatic Cleaning

The ClearO2 T200 unit has an automatic cleaning function by reverse compressed air pulse. The moment the under pressure in the filter is too high, the unit starts to clean the filter automatically. A manual cleaning function can be done by pressing a single button. The automatic Start/Stop function to preserve energy and to synchronize the unit with the 8TE TIG Extractor is a standard on the ClearO2 units. The moment the torch is out of the specially designed torch holder option, the machine automatically starts working.

Continuous rated motor

The electric motor of the unit is designed to work continuously without losing its power. Due to the automatic cleaning function and the simplified motor system, the maintenance of the unit is minimal, making it long-lasting and time-saving. With a filter area of 5m², this is one of the most efficient units of its size with the largest filter. The filter is disposable and has an active surface with an efficiency: IFA >99,8%.

Light and Mobile

The ClearO2 T200 unit is designed to serve the needs of two welders, who needs to change their work-place. Examples for such applications are in shipbuilding, wind tower building, tank construction and other similar fabrication industries. The four wheels with two locks and the lightweight – only 45kg – let the welder move the unit with ease to the next working location.

The ClearO2 unit is available with a power supply of 220V-240V (W100) or 380-480V (W150) and CE and W3 certified.

Specifications

The ClearO2 W100/ W150 is designed to accompany the 8XE MIG and 7XE MIG Extractors from Translas. With the combination of the 8XE MIG and 7XE MIG Extractors range of welding fume torches and ClearO2 W100/150 units we capture between 90% and 98% of welding fume at the source and filter these with efficiency > IFA 99.8%. The compact unit is perfect for changing location on the job due to its lightweight – only 45 kg – and its four wheels with two lockable.

Automatic Cleaning

The ClearO2 W100/ W150 unit has an automatic cleaning function by reverse compressed air pulse. The moment the under pressure in the filter is too high, the unit starts to clean the filter automatically. A manual cleaning function can be done by pressing a single button. Automatic Start/Stop function to preserve energy and to synchronize the unit with the 8XE MIG and 7XE MIG Extractors is a standard on the ClearO2 units. The moment the torch is out of the specially designed torch holder option, the machine automatically starts working.

Continuous rated motor

The electric motor of the unit is designed to work continuously without losing its power. Due to the automatic cleaning function and the simplified motor system, the maintenance of the unit is minimal, making it long-lasting and time-saving. With a filter area of 5m², this is one of the most efficient units of its size with the largest filter. The filter is disposable and has an active surface with an efficiency: IFA >99,8%.

Light and Mobile

The ClearO2 W100/ W150 units are designed to serve the needs of a single welder, who needs to change their work-place. Examples for such applications are in shipbuilding, wind tower building, tank construction and other similar fabrication industries. The four wheels with two locks and the lightweight – only 45kg – let the welder move the unit with ease to the next working location.

ClearO2 Two-welder mobile filtration unit

Designed for the 8XE and 7XE MIG Extractors.

Exceptional filter efficiency IFA >99.8%

Specifications

The ClearO2 W200 is designed to accompany the 8XE and 7XE MIG Extractors from Translas. With the combination of the 8XE and 7XE Extractors range of welding fume torches and ClearO2 W200 units we capture between 90% and 98% of welding fume at the source and filter these with efficiency > IFA 99.8%. The compact unit is perfect for changing location on the job due to its lightweight – only 58 kg – and its four wheels with two lockable.

Automatic Unit

The ClearO2 W200 unit has an automatic cleaning function by reverse compressed air pulse. The moment the pressure in the filter is too high, the unit starts to clean the filter automatically. A manual cleaning function can be done by pressing a single button. Automatic start/stop function to preserve energy and to synchronize the unit with the 8XE and 7XE Extractors is a standard on the ClearO2 units. The moment the torch is out of the specially designed torch holder, the machine automatically starts working. The torch holder is designed to work only with the 8XE and 7XE MIG Extractor.

Continuous Rated Motor

The electric motor of the unit is designed to work continuously without losing power. Maintenance on the unit is minimal due to the automatic cleaning function and the simplified motor system, making it long-lasting and time-saving. With a filter area of 5m², this is one of the most efficient units of its size with the largest filter. The filter is disposable and has an active surface with an efficiency: IFA >99,8%.

Light And Mobile

The ClearO2 W200 unit is designed to serve the needs of a welder, who needs to move around their workplace. Examples for such applications are in shipbuilding, wind tower building, tank construction and other similar fabrication industries. The four wheels with two locks and the lightweight – only 58kg – allow the welder to move the unit with ease to the next working location.

Multi-player Solution

The ClearO2 units are a practical solution for every welding fabrication environment. The W200 units start with a 2-welder solution! Easily switch between single and multiplayer mode by connecting only the amount of extraction torches you need.

Ball valve to reduce the suction flow

Coupler for suction hose black tbv Ø51mm unit side

Coupler to extend the suction hose Ø51mm

Extension cable auto start/stop 5-p plug W-serie

Specifications

• Extension cable auto start/stop 3mtr incl. 5-p plug W-serie
• Extension cable auto start/stop 5mtr incl. 5-p plug W-serie
• Extension cable auto start/stop 3mtr incl. 10-p plug W-serie

Filter W-serie ClearO2

Specifications

• Filter W-serie ClearO2 5m2

Filtermat W-serie ClearO2

Specifications

• Filtermat W-serie ClearO2 (set/5pc)

Pressure reducing valve 5-15bar 1/4-NP7.2

Sensing cable auto start/stop 4mtr W-serie

Specifications

• Sensing cable auto start/stop 4mtr W-serie

Suction hose for the ClearO2

Specifications

• ClearO2 suction hose black Ø51m 5mtr
• ClearO2 suction hose black Ø51m 10mtr

Torch holder for automatic start/stop

Specifications

• Torch holder Ø40mm for automatic start/stop 5mtr ClearO2
• Torch holder Ø40mm for automatic start/stop 10mtr ClearO2
• Torch holder Ø50mm for automatic start/stop 5mtr ClearO2
• Torch holder Ø55mm for automatic start/stop 10mtr ClearO2

Flip up welding goggles

Specifications

HC Anti-scratch

AF Anti-fog

W5 Shade 5

Safety grinding goggles

Specifications

HC Anti-scratch

AF Anti-fog

Clear

Yellow

Grey

Specifications

Clear / Yellow / Grey lens

HC Anti-scratch

AF Anti-fog

Clear

Indoor/Outdoor lens

Yellow

Specifications

Clear / Yellow / Grey lens

HC Anti-scratch

AF Anti-fog

Clear

Yellow

Grey

Specifications

Clear / Yellow / Grey lens

HC Anti-scratch
AF Anti-fog

Clear

Yellow

Grey

Specifications

Clear / Yellow / Grey lens

HC Anti-scratch

AF Anti-fog

Goggles

Clear

Specifications

Clear lens

HC Anti-scratch

AF Anti-fog

T230

Specifications

Sizes 8-11

T240

Specifications

Sizes 7-11

T268

Specifications

Sizes 8,10,11

T275

Specifications

Sizes 8-12

T480

Specifications

Sizes 8,10

T580

Specifications

Sizes 6-11

T88

Specifications

Sizes 8-11

Extended hood and leather coverage

Specifications

Extended Hood for Welding Helmet

Extended hood made out of durable flame-retardant cotton. It is suitable for overhead welding and helps on-site and field welders be protected against burns caused be welding spatter.

Can be ordered together or separately

Characteristics:

• Is Washable and durable
• Fits all FORCE welding helmets
• Has special stay-on rubber fit
• Blocks out ambient lights coming from behind the welder.

Force 300 Automatic welding helmet

Specifications

Force 300

• Optical class: 1 / 2 / 1 / 2;
• Viewing area 98x44mm (3.86″x1.73″)
• Cartridge size 110x90x9mm (4.33″x3.54″x0.35″)
• Arc sensor 2
• Light state DIN 3.5
• Dark state Variable Shade 9 ~ 13
• Shade control External, Variable Shade
• Power On/Off Automatic on/off
• Sensitivity control Low — High, by infinitely dial knob
• UV/IR Protection Up to Shade DIN16 at all times
• Power supply Solar cell. No battery change required
• Switching time 1/16.000s. from light to dark
• Dark to light 0.25 ~ 0.30s (fast) to 0.65 ~ 0.80s (slow) by infinitely dial knob
• Low amperage TIG rated ≥ 10 amps / DC; ≥ 10 amps / AC
• Grinding Yes
• Operating temperature -10°C~ +55°C (14°F ~ 131°F)
• Storing temperature -20°C~ +70°C (- 4°F ~ 158°F)
• Material helmet High Impact Resistance Nylon
• Total weight, with helmet 440g
• Application range Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Grinding;
• Approved DINplus, CE, ANSI Z87.1, CSA Z94.3, AS/NZS

Force 700 Automatic welding helmet

Specifications

Force 710S

• Optical class : 1 / 1 / 1 / 1
• Viewing area 97x47mm (3.82″x1.85″)
• Cartridge size 110x90x9mm (4.33″x3.54″x0.35″)
• Arc sensor 2
• Light state DIN 3.5
• Dark state Variable Shade 9 ~ 13
• Shade control Internal, Variable Shade
• Power On/Off Fully Automatic
• Sensitivity control Low — High, by infinitely dial knob
• UV/IR Protection Up to Shade DIN16 at all times
• Power supply Solar cell. Battery change required;1 x CR2450 lithium battery
• Switching time 1/25.000s. from light to dark
• Dark to light 0.1 ~ 1.0s by infinitely dial knob
• Low amperage TIG rated ≥ 2 amps / DC; ≥ 2 amps / AC
• Grinding Yes
• Operating temperature -10°C~ +55°C (14°F ~ 131°F)
• Storing temperature -20°C~ +70°C (- 4°F ~ 158°F)
• Material helmet High Impact Resistance Nylon
• Total weight, with helmet 440g
• Application range: Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Grinding
• Approved: CE, ANSI Z87.1, CSA Z94.3, AS/NZS

Force 730S

• Optical class: 1 / 1 / 1 / 2
• Viewing area 95x62mm (3.74″x2.44″)
• Cartridge size 110x90x9mm (4.33″x3.54″x0.35″)
• Arc sensor 4
• Light state DIN 3.5
• Dark state Variable Shade 5~ 8 / 9 ~ 13
• Shade control External, Variable Shade
• Power On/Off Fully Automatic
• Sensitivity control Low — High, by infinitely dial knob
• UV/IR Protection Up to Shade DIN16 at all times
• Power supply Solar cell. Battery change required;1 x CR2450 lithium battery
• Switching time 1/25.000s. from light to dark
• Dark to light 0.1 ~ 1.0s by infinitely dial knob
• Low amperage TIG rated ≥ 2 amps / DC; ≥ 2 amps / AC
• Grinding Yes
• Operating temperature -10°C~ +55°C (14°F ~ 131°F)
• Storing temperature -20°C~ +70°C (- 4°F ~ 158°F)
• Material helmet High Impact Resistance Nylon
• Total weight, with helmet 445g
• Application range: Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Oxyfuel Gas Welding (OFW); Oxygen Cutting (OC); Grinding
• Approved: CE, ANSI Z87.1, CSA Z94.3, AS/NZS

Force 800 Automatic welding helmet

Specifications

Force 820S:

• Optical class 1 / 1 / 1/ 1
• Viewing area 95x85mm (3.74″x3.35″)
• Cartridge size 133x114x9mm (5.24″x4.50″x0.35″)
• Arc sensor 4
• Light state DIN 3.5
• Dark state Variable Shade 6 ~ 9 / 9 ~ 13
• Shade control Internal, Variable Shade
• Power Automatic On / Off
• Sensitivity control Low — High, by infinitely dial knob
• UV/IR Protection Up to Shade DIN16 at all times
• Power supply “Solar cell. Battery change required; 1 x CR2450 lithium battery
• Switching time 1/25.000s. from light to dark
• Dark to light 0.1 ~ 1.0s by infinitely dial knob
• Oxyfuel gas welding Yes
• Oxygen cutting Yes
• Grinding Yes
• Low amperage TIG rated ≥ 2 amps / DC; ≥ 2 amps / AC
• Operating temperature -10°C~ +55°C (14°F ~ 131°F) *Suitable For High Temperature Welding
• Storing temperature -20°C~ +70°C (- 4°F ~ 158°F)
• Material helmet High Impact Resistance Nylon
• Total weight, with helmet 490g
• Application range Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Oxyfuel Gas Welding (OFW); Oxygen Cutting (OC); Grinding;
• Approved CE, ANSI Z87.1, CSA Z94.3, AS/NZS

Force 830S:

• Optical class 1 / 1 / 1/ 1
• Viewing area 97x62mm (3.82″x2.44″)
• Cartridge size 133x114x9mm (5.24″x4.50″x0.35″)
• Arc sensor 4
• Light state DIN 3.5
• Dark state Variable Shade 5~ 8 / 8 ~ 13
• Shade control Internal, Variable Shade;Digital Display Control
• Power Manual-on, Auto-off
• Sensitivity control Low — High, Digital Display Control
• UV/IR Protection Up to Shade DIN16 at all times
• Power supply Solar cell. Battery change required; 2 x CR2450 lithium battery
• Switching time 1/25.000s. from light to dark
• Dark to light 0.1 ~ 1.0s Digital Display Control
• Oxyfuel gas welding Yes
• Oxygen cutting Yes
• Grinding Yes
• Low amperage TIG rated ≥ 2 amps / DC; ≥ 2 amps / AC
• Operating temperature -10°C~ +55°C (14°F ~ 131°F) *Suitable For High Temperature Welding
• Storing temperature -20°C~ +70°C (- 4°F ~ 158°F)
• Material helmet High Impact Resistance Nylon
• Total weight, with helmet 490g
• Application range Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Oxyfuel Gas Welding (OFW); Oxygen Cutting (OC); Grinding;
• Approved CE, ANSI Z87.1, CSA Z94.3, AS/NZS

Force 900 Automatic Welding Helmet

With flip-up lens

Suitable for welding, grinding and cutting

Specifications Force 900 Welding Helmet

The automatic Force 900 welding helmet has the welder covered in every situation – welding, grinding and cutting.

ClearView

Cartridge is equipped with ClearView Technology, which provides you with an ultra-clear view during welding.

Digital Display Control

The Force 900 Digital Display Control has a clear interface design. You can switch between different modes within seconds. It also has a memory function which allows you to save the set parameters when switching between modes.

Multi-Functional Flip-UP Design

The Force 900 is a flip-up helmet with easy lift for grinding function, suiting welding/cutting/grinding mode. The transparent grinding lens is curved with a large view area of (20 x 12 cm). The welding lens with the highest optical glass -1/1/1/1- provides an exceptionally clear view of the arc during welding.

Technical Specifications Helmet

• • Optical Class: 1/1/1/1
  • Viewing Area: 107 x 75mm (4.21” x 2.95”)
  • Cartridge Size: 156 x 123 x 33 mm (6.14” x 4.84” x 1.30”)
  • Arc Sensor: 4
  • Grind state: DIN4
  • Light state: DIN4
  • Cutting shade: Shade No. from 5 to 8
  • Shade No. from 9 to 13
  • Shade Control: Internal, Digital Display Control
  • UV / IR Protection: Up to shade DIN13 at all times
  • Power Supply: Solar cell. Battery replaceable, 2x CR2450 lithium battery.
  • Switching Time: 1/25,000 s. from Light to Dark
  • Grinding: Yes
  • Delay (Dark to Light): 0.1 ~ +55°C (14 °F ~ 131 °F)

20 °C ~ +70 °C (-4 °F ~ 158 °F)

• Helmet Material: High Impact Resistance Nylon
• Total Weight: 765 grams
• Application Range: Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC) Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Oxyfuel Gas Welding (OFW); Oxygen Cutting (OC); Grinding.
• Approved: DINplus, ANSI Z87.1, CSA Z94.3, AS/NZS 1338.1

PAPR Fresh air system

Specifications

Inhaled air 50 times cleaner than air in the immediate area

TH2 approved

Comfortable to wear

Unique design

Suitable for grinding and cutting

Easy to clean head cap

AirForce Fresh air set with flip-up helmet

Specifications

• Flip-up design
• Large view for grinding
• Auto-alarm system
• Rechargeable Li-ion battery
• Respiratory protection
• Intelligent air supply
• Real-time display indicator

P.N.: 570400

This product could be used in below field:

1- Isolating ward and medical observation site

2-Transfer of the infected

3-Corpse treatment

4-Environment disinfection

5-Sample collection

6-Laboratory testing

Ultrasonic seaming technology

Seamed with ultrasonic welding, with high-intensity feature and longer lifetime.

Multi-layer fabric

Lightweight specialized fabric. TM-H2 with a longer length to protect neck and shoulder.

Full view visual field

Large window size, curved design to better fit face-line, expanding the visual field.

Adjustable headgear

Adjustable headgear, with soft sweatband, improving the wearing comfort.

10XR Robotic 500 MIG Fume Extraction Torch – Water COOLED
MIXED GASES – 500 AMP, DUTY CYCLE – 100%

With the 10XR Robotic MIG Extraction Torch, harmful welding fumes can be safely and effectively extracted right at the source directly through the gun.

When the 10XR Robotic Welding Fumes Extractor is used with the ClearO2 W-Series 100 and 200, it allows for up to 98% of welding fume removal, which forms during the welding process. The fumes are extracted directly from the point of origin, through the nozzle before entering the atmosphere.

In addition to cleaner air, your employees will be able to work in a more pleasant environment.

By using the 10XR Robotic Welding Fumes Extractor, you have significantly less investment in alternative extraction options as it eliminates the requirement of a hood, curtain and larger powerful extraction systems being installed.

Experience significant savings with the 10XR with lower initial investment costs, lower operating costs and minimized maintenance costs including cleaning and filter life. Experience energy efficiencies compared to the current Industrial robot solutions that are available today.

8XC Cobot 500 MIG Fume Extraction Torch – Water COOLED
CO2 – 550 AMP, MIXED GASES – 500 AMP, DUTY CYCLE – 100%

The 8XC Cobot Fume Extractor reduces welding fume Up To 98% and has a unique contact tip for manual fitting and durability. Moreover, This cobot extractor gun designs a special contact tip for a longer lifetime. Also, we created two unique nozzles, 14mm and 17mm, for optimal performance and durability.

It is designed to be one of the most efficient fume extraction systems available in the welding industry. This torch is available in four different angles: 22°, 35°, 45°, and straight. When the 8XC Cobot MIG Fume Extractor is used with the ClearO2 W-series 100 and 200, it allows for up to 98% of welding fumes to be captured directly at the fume source. As a result, this Cobot 8XC MIG Fume Extractor is one of the safest and most effective extraction solutions available to ensure the safety of welding workers and for better working environments and working with the UR10e, UR5e, & UR16e Universal Robots.

HOW DOES IT WORK?
The 8XC MIG Fume Extractor is specifically designed for use by Cobots and Semi-Automated machines. There is a special design of nozzle on the 8XC and the combination of the unique design with the ClearO2 W-series, 100 and 200, provides the most effective results in the direct extraction of fumes from the source. In addition, the nickel-plated contact tips are designed to last a longer time than the other contact tips on the market. These tips are available for use with all kinds of wires and in different sizes. The 8XC MIG Cobot fume extractor can use three types of Universal Robots: UR5e, UR10e, and UR16e.

To achieve the most outstanding results possible, the nozzle is unique in design. The openings, wall thickness, and size are all special to the nozzle. In addition, we have developed the grip ribs so that they perform optimally for optimal operation and superior performance.

8XC MINI Cobot 250 MIG Fume Extraction Torch – AIR COOLED
CO2 – 280 AMP, MIXED GASES – 250 AMP, DUTY CYCLE – 100%

The 8XC Cobot Fume Extractor reduces welding fume Up To 98% and has a unique contact tip for manual fitting and durability. Moreover, This cobot fume extractor gun designs a special contact tip for a longer lifetime. Also, we created two unique nozzles, 14mm and 17mm, for optimal performance and durability.

It is designed to be one of the most efficient extraction systems available in the welding industry. This torch is available in four different angles: 22°, 35°, 45°, and straight. When the 8XC Cobot MIG Fume Extractor is used with the ClearO2 W-series 100 and 200, it allows for up to 98% of welding fumes to be captured directly at the fume source. As a result, the Cobot 8XR is one of the safest and most effective welding fume extraction solutions available to ensure the safety of welding workers and for better working environments and working with the UR10e, UR5e, & UR16e Universal Robots.

HOW DOES IT WORK?
The 8XC MIG Fume Extractor is specifically designed for use by Cobots and Semi-Automated machines. There is a special design of nozzle on the 8XC and the combination of the unique design with the ClearO2 W-series, 100 and 200, provides the most effective results in the direct extraction of fumes from the source. In addition, the nickel-plated contact tips are designed to last a longer time than the other contact tips on the market. These tips are available for use with all kinds of wires and in different sizes. The 8XC MIG Cobot fume extractor can use three types of Universal Robots: UR5e, UR10e, and UR16e.

To achieve the most outstanding results possible, the nozzle is unique in design. The openings, wall thickness, and size are all special to the nozzle. In addition, we have developed the grip ribs so that they perform optimally for optimal operation and superior performance.

8XR COBOT MIG EXTRACTOR – Water COOLED
CO2 – 550 AMP, MIXED GASES – 500 AMP, DUTY CYCLE – 100%

Specifications:
Reduces Welding Fume Up To 98%
Unique contact tip for manual fitting and durability.
Special design contact tip for longer lifetime.
Two unique nozzle design 14mm and 17mm for optimal performance and durability

The 8XR Cobot MIG Extractor integrates the most efficient fume extraction structure in the welding industry.
The torch comes with four different angles 22, 35°, 45° and straight. The 8XR Cobot MIG Extractor, combined
with the ClearO2 W-series 100 and 200, captures up to 98% of welding fumes directly at the source.
The 8XR Cobot MIG Extractor provides the safest and most effective solution for welders and workers to
breathe CLEAN AIR and better work environments

35% Duty cycle

160 Amp. – DC

120 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

160 Amp. – DC

120 Amp. – AC/DC

Air cooled

35% Duty cycle

140 Amp. – DC

100 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

140 Amp. – DC

100 Amp. – AC/DC

Air cooled

35% Duty cycle

80 Amp. – DC

60 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

80 Amp. – DC

60 Amp. – AC/DC

Air cooled

35% Duty cycle

180 Amp. – DC

130 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

180 Amp. – DC

130 Amp. – AC/DC

Air cooled

35% Duty cycle

300 Amp. – DC

250 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

300 Amp. – DC

250 Amp. – AC/DC

Air cooled

35% Duty cycle

110 Amp. – DC

80 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

110 Amp. – DC

80 Amp. – AC/DC

Air cooled

35% Duty cycle

160 Amp. – DC

120 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

160 Amp. – DC

120 Amp. – AC/DC

Air cooled

35% Duty cycle

140 Amp. – DC

100 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

140 Amp. – DC

100 Amp. – AC/DC

Air cooled

100% Duty cycle

320 Amp. – DC

230 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

320 Amp. – DC

230 Amp. – AC/DC

Water cooled

100% Duty cycle

400 Amp. – DC

280 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

400 Amp. – DC

280 Amp. – AC/DC

Water cooled

100% Duty cycle

220 Amp. – DC

165 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

220 Amp. – DC

165 Amp. – AC/DC

Water cooled

35% Duty cycle

80 Amp. – DC

60 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

80 Amp. – DC

60 Amp. – AC/DC

Air cooled

100% Duty cycle

210 Amp. – DC

165 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

210 Amp. – DC

165 Amp. – AC/DC

Water cooled

100% Duty cycle

250 Amp. – DC

175 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

250 Amp. – DC

175 Amp. – AC/DC

Water cooled

35% Duty cycle

180 Amp. – DC

130 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

180 Amp. – DC

130 Amp. – AC/DC

Air cooled

35% Duty cycle

300 Amp. – DC

250 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

300 Amp. – DC

250 Amp. – AC/DC

Air cooled

35% Duty cycle
110 Amp. – DC
80 Amp. – AC/DC
Air cooled

100% Duty cycle

350 Amp. – DC

250 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

350 Amp. – DC

250 Amp. – AC/DC

Water cooled

100% Duty cycle

450 Amp. – DC

360 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

450 Amp. – DC

360 Amp. – AC/DC

Water cooled

35% Duty cycle

110 Amp. – DC

80 Amp. – AC/DC

Air cooled

Specifications

35% Duty cycle

110 Amp. – DC

80 Amp. – AC/DC

Air cooled

100% Duty cycle

320 Amp. – DC

230 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

320 Amp. – DC

230 Amp. – AC/DC

Water cooled

100% Duty cycle

400 Amp. – DC

280 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

400 Amp. – DC

280 Amp. – AC/DC

Water cooled

100% Duty cycle

220 Amp. – DC

165 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

220 Amp. – DC

165 Amp. – AC/DC

Water cooled

100% Duty cycle

210 Amp. – DC

165 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

210 Amp. – DC

165 Amp. – AC/DC

Water cooled

100% Duty cycle

250 Amp. – DC

175 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

250 Amp. – DC

175 Amp. – AC/DC

Water cooled

35% Duty cycle
110 Amp. – DC
80 Amp. – AC/DC
Air cooled

100% Duty cycle

350 Amp. – DC

250 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

350 Amp. – DC

250 Amp. – AC/DC

Water cooled

100% Duty cycle

450 Amp. – DC

360 Amp. – AC/DC

Water cooled

Specifications

100% Duty cycle

450 Amp. – DC

360 Amp. – AC/DC

Water cooled

Click on Product Sheet for configuration

1-Button
Lamelle
2-Button
3-button
4-Button Rocker
1-Button Potentiometer

Specifications

Click Product Sheet for more specifications

FLEX hose nylon braded

TPU hose reinforced

Fuel hose reinforced

Rubber hose reinforced

Silicon hose nylon braded

PROFLEX hose nylon braded

Specifications

FLEX hose nylon braded – standard 100
TPU hose reinforced 100
Fuel hose reinforced 100
Rubber hose reinforced 100
Silicon hose nylon braded 100
PROFLEX hose nylon braded 100

Ceramic cup 9/20/25F/30

Ceramic cup 17/18/26

Ceramic cup 24/24W

Ceramic cup 121/301

Ceramic cup short 121/301

Ceramic cup 450

Ceramic gas lens cup 9/20/24/24W/25F/30

Ceramic gas lens cup 17/18/18SC/26/121/301

Ceramic gas lens cup XL 17/18/26

Ceramic gas lens cup 450

Specifications

13N08 Ceramic cup 6.4mm 9/20/25F/30
13N09 Ceramic cup 7.9mm 9/20/25F/30
13N10 Ceramic cup 9.5mm 9/20/25F/30
13N11 Ceramic cup 11.1mm 9/20/25F/30
13N12 Ceramic cup 12.7mm 9/20/25F/30
13N13 Ceramic cup 15.9mm 9/20/25F/30

10N50 Ceramic cup 6.4mm 17/18/26
10N49 Ceramic cup 7.9mm 17/18/26
10N48 Ceramic cup 9.5mm 17/18/26
10N47 Ceramic cup 11.1mm 17/18/26
10N46 Ceramic cup 12.7mm 17/18/26
10N45 Ceramic cup 16.0mm 17/18/26
10N44 Ceramic cup 19.0mm 17/18/26

53N23 Ceramic cup 4.2mm 24/24W
53N24 Ceramic cup 6.4mm 24/24W
53N25 Ceramic cup 7.9mm 24/24W
53N27 Ceramic cup 9.5mm 24/24W

0315035 Ceramic cup 9.8mm 121/301
0315037 Ceramic cup 11.1mm 121/301

0315033 Ceramic cup short 8.0mm 121/301
0315034 Ceramic cup short 9.8mm 121/301
0315036 Ceramic cup short 11.1mm 121/301

0314201 Ceramic cup 9.8mm 450
0314202 Ceramic cup 12.7mm 450
0314203 Ceramic cup 15.9mm 450

3N58 Ceramic gas lens cup 6.4mm 9/20/24/24W/25F/30 10
53N59 Ceramic gas lens cup 7.9mm 9/20/24/24W/25F/30 10
53N60 Ceramic gas lens cup 9.5mm 9/20/24/24W/25F/30 10
53N61 Ceramic gas lens cup 11.1mm 9/20/24/24W/25F/30 10
53N61S Ceramic gas lens cup 12.7mm 9/20/24/24W/25F/30 10

54N18/0315080 Ceramic gas lens cup 6.4mm 17/18/18SC/26/121/301 10
54N17/0315081 Ceramic gas lens cup 8.0mm 17/18/18SC/26/121/301 10
54N16/0315082 Ceramic gas lens cup 9.5mm 17/18/18SC/26/121/301 10
54N15/0315083 Ceramic gas lens cup 11.1mm 17/18/18SC/26/121/301 10
54N14/0315084 Ceramic gas lens cup 12.7mm 17/18/18SC/26/121/301 10
54N19 Ceramic gas lens cup 17.5mm 17/18/18SC/26 10

57N75 Ceramis gas lens cup XL 9.5mm 17/18/26 5
57N74 Ceramic gas lens cup XL 12.7mm 17/18/26 5
53N88 Ceramic gas lens cup XL 16.0mm 17/18/26 5
53N87 Ceramic gas lens cup XL 19.0mm 17/18/26 5
53N89 Ceramic gas lens cup XL 23.8mm 17/18/26 5

0314301 Ceramic gas lens cup 9.8mm 450 10
0314302 Ceramic gas lens cup 12.7mm 450 10
0314303 Ceramic gas lens cup 15.9mm 450

Collet body 9/20/25F/30

Collet body 17/18/26

Collet body stubby 17/18/26

Collet body 24/24W

Specifications

13N26 Collet body 1.0mm 9/20/25F/30
13N27 Collet body 1.6mm 9/20/25F/30
70067 Collet body 2.0mm 9/20/25F/30
13N28 Collet body 2.4mm 9/20/25F/30
13N29 Collet body 3.2mm 9/20/25F/30

10N30 Collet body 1.0mm 17/18/26
10N31 Collet body 1.6mm 17/18/26
70064 Collet body 2.0mm 17/18/26
10N32 Collet body 2.4mm 17/18/26
70065 Collet body 3.0mm 17/18/26
10N28 Collet body 3.2mm 17/18/26
406488 Collet body 4.0mm 17/18/26

17CB24 Collet body stubby 3,2mm 17/18/26

53N18 Collet body 1.0mm 24/24W
53N19 Collet body 1.6mm 24/24W
24CB332 Collet body 2.4mm 24/24W

Collet 9/20/25F/30

Collet 17/18/26

Collet stubby 17/18/26

Collet HD 18SC

Collet 24/24W

Collet for gas lens 24/24W

Collet 121/301

Collet 450

Specifications

13N21 Collet 1.00mm 9/20/25F/30
13N22 Collet 1.6mm 9/20/25F/30
70066 Collet 2.0mm 9/20/25F/30
13N23 Collet 2.4mm 9/20/25F/30
13N24 Collet 3.2mm 9/20/25F/30

10N22 Collet 1.0mm 17/18/26
10N23 Collet 1.6mm 17/18/26
700N62 Collet 2.0mm 17/18/2
10N24 Collet 2.4mm 17/18/26
70063 Collet 3.0mm 17/18/26
10N25 Collet 3.2mm 17/18/26
10N25 Collet 4.0mm 17/18/26

10N23S Collet stubby 1.6mm 17/18/26
10N24S Collet stubby 2.4mm 17/18/26
10N25S Collet stubby 3.2mm 17/18/26

10N24HD Collet HD 2.4mm 18SC
10N25HD Collet HD 3.2mm 18SC
10N20HD Collet HD 4.0mm 18SC

53N16 Collet 1.0mm 24/24W
53N14 Collet 1.6mm 24/24W
24C332 Collet 2.4mm 24/24W

53N63 Collet for gas lens 1.0m 24/24W
53N64 Collet for gas lens 1.6m 24/24W
53N64s Collet for gas lens 2.4m 24/24W

0315021 Collet 1.6mm 121/301
0315022 Collet 2.4mm 121/301
0315023 Collet 3.2mm 121/301
0315024 Collet 4.0mm 121/301

0314101 Collet 1.6mm 450
0314102 Collet 2.4mm 450
0314103 Collet 3.2mm 450
0314104 Collet 4.0mm 450
0314105 Collet 4.8mm 450

TIG-9/17/121

TIG-9/17/121

TIG-18/18C/301

TIG-20/24W/25F

TIG-24

TIG-26

TIG-26

TIG-450

Specifications

End fitting for TIG-9/17/121
End fitting for TIG-9/17/121 (separate gas- and power cable)
End fitting for TIG-18/18C/301
End fitting for TIG-20/24W/25F

End fitting for TIG-24
End fitting for TIG-26
End fitting for TIG-26 (separate gas- and power cable)
End fitting for TIG-450

Gas lens 9/20/24/24W/25F/30

Gas lens 17/18/26

Gas lens XL 17/18/26

Gas lens 18SC

Gas lens 121/301

Specifications

45V42 Gas lens 1.0mm 9/20/24/24W/25F/30
45V43 Gas lens 1.6mm 9/20/24/24W/25F/30
70058 Gas lens 2.0mm 9/20/24/24W/25F/30
45V44 Gas lens 2.4mm 9/20/24/24W/25F/30
45V45 Gas lens 3.2mm 9/20/24/24W/25F/30

45V24 Gas lens 1.0mm 17/18/26
45V25 Gas lens 1.6mm 17/18/26
70060 Gas lens 2.0mm 17/18/26
45V26 Gas lens 2.4mm 17/18/26
70061 Gas lens 3.0mm 17/18/26
45V27 Gas lens 3.2mm 17/18/26
45V28 Gas lens 4.0mm 17/18/26

45V116 Gas lens XL 1.6mm 17/18/26
45V64 Gas lens XL 2.4mm 17/18/26
995795 Gas lens XL 3.2mm 17/18/26
45V63 Gas lens XL 4.0mm 17/18/26

18GL16 Gas lens 1.6mm 18SC
18GL32 Gas lens 2.4mm 18SC
18GL18 Gas lens 3.2mm 18SC
18GL53 Gas lens 4.0mm 18SC

0316025 Gas lens 1.6mm 121/301
0316026 Gas lens 2.4mm 121/301
0316027 Gas lens 3.2mm 121/301
0316028 Gas lens 4.0mm 121/301

CO2 180 Amp

Mixed gases 150 Amp

Duty cycle 60%

Air-cooled

Specifications

CO2 180 Amp

Mixed gases 150 Amp

Duty cycle 60%

Air-cooled

CO2 – 180 Amp

Mixed gases 150 Amp

Duty cycle 60%

Air-cooled

Specifications

CO2 – 180 Amp

Mixed gases 150 Amp

Duty cycle 60%

Air-cooled

CO2 – 250 Amp

Mixed gases – 220 Amp

Duty cycle 60%

Air-cooled

Specifications

CO2 – 250 Amp

Mixed gases – 220 Amp

Duty cycle 60%

Air-cooled

CO2 – 250 Amp

Mixed gases – 200 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 250 Amp

Mixed gases – 200 Amp

Duty Cycle – 60%

Air-cooled

CO2 – 230 Amp

Mixed gases – 200 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 230 Amp

Mixed gases – 200 Amp

Duty cycle – 60%

Air-cooled

CO2 – 230 Amp

Mixed gases – 200 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 230 Amp

Mixed gases – 200 Amp

Duty cycle – 60%

Air-cooled

CO2 – 320 Amp

Mixed gases – 300 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 320 Amp

Mixed gases – 300 Amp

Duty cycle – 60%

Air-cooled

CO2 – 320 Amp

Mixed gases – 300 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 320 Amp

Mixed gases – 300 Amp

Duty cycle – 60%

Air-cooled

CO2 – 350 Amp

Mixed gases – 320 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 350 Amp

Mixed gases – 320 Amp

Duty cycle – 60%

Air-cooled

CO2 – 400 Amp

Mixed gases – 380 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 400 Amp

Mixed gases – 380 Amp

Duty cycle – 60%

Air-cooled

CO2 180 Amp

Mixed gases 150 Amp

Duty cycle 60%

Air-cooled

Specifications

CO2 180 Amp

Mixed gases 150 Amp

Duty cycle 60%

Air-cooled

CO2 – 180 Amp

Mixed gases 150 Amp

Duty cycle 60%

Air-cooled

Specifications

CO2 – 180 Amp

Mixed gases 150 Amp

Duty cycle 60%

Air-cooled

CO2 – 250 Amp

Mixed gases – 220 Amp

Duty cycle 60%

Air-cooled

Specifications

CO2 – 250 Amp

Mixed gases – 220 Amp

Duty cycle 60%

Air-cooled

CO2 – 300 Amp

Mixed gases – 270 Amp

Duty cycle – 60%

Water-cooled

Specifications

CO2 – 300 Amp

Mixed gases – 270 Amp

Duty cycle – 60%

Water-cooled

CO2 – 250 Amp

Mixed gases – 200 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 250 Amp

Mixed gases – 200 Amp

Duty Cycle – 60%

Air-cooled

CO2 – 230 Amp

Mixed gases – 200 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 230 Amp

Mixed gases – 200 Amp

Duty cycle – 60%

Air-cooled

CO2 – 230 Amp

Mixed gases – 200 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 230 Amp

Mixed gases – 200 Amp

Duty cycle – 60%

Air-cooled

CO2 – 360 Amp

Mixed gases – 340 Amp

Duty cycle – 100%

Water-cooled

Specifications

CO2 – 360 Amp

Mixed gases – 340 Amp

Duty cycle – 100%

Water-cooled

CO2 – 320 Amp

Mixed gases – 300 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 320 Amp

Mixed gases – 300 Amp

Duty cycle – 60%

Air-cooled

CO2 – 320 Amp

Mixed gases – 300 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 320 Amp

Mixed gases – 300 Amp

Duty cycle – 60%

Air-cooled

CO2 – 350 Amp

Mixed gases – 320 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 350 Amp

Mixed gases – 320 Amp

Duty cycle – 60%

Air-cooled

CO2 – 400 Amp

Mixed gases – 380 Amp

Duty cycle – 60%

Air-cooled

Specifications

CO2 – 400 Amp

Mixed gases – 380 Amp

Duty cycle – 60%

Air-cooled

CO2 – 500 Amp

Mixed gases – 450 Amp

Duty cycle – 100%

Water-cooled

Specifications

CO2 – 500 Amp

Mixed gases – 450 Amp

Duty cycle – 100%

Water-cooled

CO2 – 500 Amp

Mixed gases – 450 Amp

Duty cycle – 100%

Water-cooled

Specifications

CO2 – 500 Amp

Mixed gases – 450 Amp

Duty cycle – 100%

Water-cooled

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

Specifications

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

Specifications

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

Specifications

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

CO2 – 300 Amp

Mixed gases – 270 Amp

Duty cycle – 60%

Water-cooled

Specifications

CO2 – 300 Amp

Mixed gases – 270 Amp

Duty cycle – 60%

Water-cooled

CO2 – 360 Amp

Mixed gases – 340 Amp

Duty cycle – 100%

Water-cooled

Specifications

CO2 – 360 Amp

Mixed gases – 340 Amp

Duty cycle – 100%

Water-cooled

CO2 – 500 Amp

Mixed gases – 450 Amp

Duty cycle – 100%

Water-cooled

Specifications

CO2 – 500 Amp

Mixed gases – 450 Amp

Duty cycle – 100%

Water-cooled

CO2 – 500 Amp

Mixed gases – 450 Amp

Duty cycle – 100%

Water-cooled

Specifications

CO2 – 500 Amp

Mixed gases – 450 Amp

Duty cycle – 100%

Water-cooled

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

Specifications

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

Specifications

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

Specifications

CO2 – 550 Amp

Mixed gases – 500 Amp

100% Duty cycle

Water-cooled

One button switch

Two button switch

Potentiometer

Digital display

Specifications

8M8901 8XM Module One button switch (1B)
8M8902 8XM Module Two button switch (2B)
8M8910 8XM Module Potentiometer (10K)
306535 Quick Connect switch cable 3mtr
306536 Quick Connect switch cable 4mtr
306537 Quick Connect switch cable 5mtr
306559 Switch cable end without plug (Quick Connect)
306545 Locking clip (Quick Connect)

Connection kit suitable for Fronius

Connection kit suitable for Cloos

Direct connection – standard

Direct connection – T-piece

Specifications

Connection kit suitable for Fronius – Air cooled
Connection kit suitable for Fronius – Water cooled

Connection kit suitable for Cloos – Air cooled
Connection kit suitable for Cloos – Water cooled

Direct connection – standard
Direct connection – T-piece

M6-06-0,6mm

M6-06-1,0mm for Alu wire

M6-06-0,6mm nickel plated

Specifications

M6-06-0,6mm
M6-06-0,8mm
M6-06-0,9mm
M6-06-1,0mm
M6-06-1,2mm
M6-06-0,8mm for Alu wire
M6-06-1,0mm for Alu wire
M6-06-1,2mm for Alu wire

M6-06-0,6mm Nickel plated
M6-06-0,8mm Nickel plated
M6-06-1,0mm Nickel plated

Contact tip M6-08-0,6mm

Contact tip M6-08-0,8mm for Alu wire

Contact tip M6-08-0,8mm CuCrZr

Contact tip M6-08-0,6mm Nickel plated

Specifications

Contact tip M6-08-0,6mm
Contact tip M6-08-0,8mm
Contact tip M6-08-0,9mm
Contact tip M6-08-1,0mm
Contact tip M6-08-1,2mm
Contact tip M6-08-1,4mm
Contact tip M6-08-1,6mm

Contact tip M6-08-0,8mm for Alu wire
Contact tip M6-08-1,0mm for Alu wire
Contact tip M6-08-1,2mm for Alu wire
Contact tip M6-08-1,6mm for Alu wire

Contact tip M6-08-0,8mm CuCrZr
Contact tip M6-08-1,0mm CuCrZr
Contact tip M6-08-1,2mm CuCrZr
Contact tip M6-08-1,4mm CuCrZr
Contact tip M6-08-1,6mm CuCrZr

Contact tip M6-08-0,6mm Nickel plated
Contact tip M6-08-0,8mm Nickel plated
Contact tip M6-08-1,0mm Nickel plated
Contact tip M6-08-1,2mm Nickel plated

Contact tip M8-100-0,8mm

Contact tip M8-100-0,8mm for Alu wire

Contact tip M8-100-0,8mm CuCrZr

Contact tip M8-100-0,8mm Nickel plated

Specifications

Contact tip M8-100-0,8mm
Contact tip M8-100-0,9mm
Contact tip M8-100-1,0mm
Contact tipM8-100-1,2mm
Contact tip M8-100-1,4mm
Contact tip M8-100-1,6mm
Contact tip M8-100-2,0mm
Contact tipM8-100-2,4mm

Contact tip M8-100-0,8mm for Alu wire
Contact tip M8-100-1,0mm for Alu wire
Contact tip M8-100-1,2mm for Alu wire
Contact tip M8-100-1,6mm for Alu wire

Contact tip M8-100-0,8mm CuCrZr
Contact tip M8-100-1,0mm CuCrZr
Contact tip M8-100-1,2mm CuCrZr
Contact tip M8-100-1,4mm CuCrZr
Contact tip M8-100-1,6mm CuCrZr

Contact tip M8-100-0,8mm Nickel plated
Contact tip M8-100-1,0mm Nickel plated
Contact tip M8-100-1,2mm Nickel plated
Contact tip M8-100-1,4mm Nickel plated

Universal adapter and Lincoln tail

Fits all Translas standard MIG torches

Specifications

Universal adapter and Lincoln tail
Fits all Translas standard MIG torches

blue/ red / yellow / plain

3 mtr , 4 mtr , 5 mtr and per mtr

Specifications

Blue liner (1.5/4.5) 3mtr
Blue liner (1.5/4.5) 4mtr
Blue liner (1.5/4.5) 5mtr
Blue liner (1.5/4.5) p/mtr
Red liner (2.0/4.5) 3mtr
Red liner (2.0/4.5) 4mtr
Red liner (2.0/4.5) 5mtr
Red liner (2.0/4.5) p/mtr
Yellow liner (2.5/4.5) 3mtr
Yellow liner (2.5/4.5) 4mtr
Yellow liner (2.5/4.5) 5mtr
Yellow liner (2.5/4.5) p/mtr

Plain liner (2.0/4.0) 3mtr
Plain liner (2.0/4.0) 4mtr
Plain liner (2.0/4.0) 5mtr
Plain liner (2.0/4.0) p/mtr
Plain liner (2.0/4.5) 3mtr
Plain liner (2.0/4.5) 4mtr
Plain liner (2.0/4.5) 5mtr
Plain liner (2.0/4.5) p/mtr
Plain liner (2.5/4.0) 3mtr
Plain liner (2.5/4.0) 4mtr
Plain liner (2.5/4.0) 5mtr
Plain liner (2.5/4.0) p/mtr
Plain liner (2.5/4.5) 3mtr
Plain liner (2.5/4.5) 4mtr
Plain liner (2.5/4.5) 5mtr
Plain liner (2.5/4.5) p/mtr

Blue liner Teflon (1.5/4.0) 3mtr
Blue liner Teflon (1.5/4.0) 4mtr
Blue liner Teflon (1.5/4.0) 5mtr
Blue liner Teflon (1.5/4.0) p/mtr
Red liner Teflon (2.0/4.0) 3mtr
Red liner Teflon (2.0/4.0) 4mtr
Red liner Teflon (2.0/4.0) 5mtr
Red liner Teflon (2.0/4.0) p/mtr
Yellow liner Teflon (2.7/4.7) 3mtr
Yellow liner Teflon (2.7/4.7) 4mtr
Yellow liner Teflon (2.7/4.7) 5mtr
Yellow liner Teflon (2.7/4.7) p/mtr

Black liner Teflon (1.5/4.0) p/mtr
Black liner Teflon (2.0/4.0) p/mtr
Black liner Teflon (2.7/4.7) p/mtr
Black liner Graphite (2.0/4.0) p/mtr
Black liner Graphite (2.3/4.7) p/mtr
Black liner Graphite (2.9/4.7) p/mtr

Collet for teflon liner 4.0mm
Collet for teflon liner 4.7mm
O-ring for teflon liner 4×1,5mm
Brass wire for graphite liner 4,0mm

CC complete

Quick connector machine side

Quick connector male

Quick connector female

Specifications

CA complete – type 502 (Guide tube L=91mm – M10x1)
CA complete – type 506 (Guide tube L=102mm – M12x1)
CA complete – type 530 (Guide tube L=120mm – ø16mm – ø12mm)

Quick connector machine side with 6mm nipple
Quick connector machine side with 8mm nipple

Quick connector 1/8’G male
Quick connector 1/4’G male
Quick connector 3/8’G male

Quick connector with M12x1 female nut
Quick connector with 1/4’G female nut
Quick connector with 3/8’G female nut

Universal adapter and Miller tail

Fits all Translas standard MIG torches

Specifications

Universal adapter and Miller tail

Fits all Translas standard MIG torches

TR-15

TR-24

TR-25

TR-36

TR-401/501

TR-401/401 Heavy Duty

7XM-450

7XM-550/560

Specifications

TR-15 Nozzle cylindrical ø 16,1mm
TR-15 Nozzle conical ø 12mm
TR-15 Nozzle tapered ø 10,5mm
TR-15 Nozzle bottleneck ø 13mm
TR-24 Nozzle cylindrical ø 17,1mm
TR-24 Nozzle conical ø 12,5mm
TR-24 Nozzle tapered ø 10mm
TR-25 Nozzle cylindrical ø 18mm
TR-25 Nozzle conical ø 15mm
TR-25 Nozzle tapered ø 12mm
TR-25 Nozzle bottleneck ø 14mm
TR-36 Nozzle cylindrical ø 20,1mm
TR-36 Nozzle conical ø 16mm
TR-36 Nozzle tapered ø 14mm
TR-401/501 Nozzle cylindrical ø 20,1mm
TR-401/501 Nozzle conical ø 16mm
TR-401/501 Nozzle tapered ø 14mm
TR-401/501 Nozzle bottleneck ø 15,1mm
TR-401/501 Nozzle cylindrical Heavy Duty ø 19,1mm
TR-401/501 Nozzle conical Heavy Duty ø 16mm
TR-450 Nozzle cylindrical ø 14,5mm
TR-450 Nozzle conical ø 14,5mm
TR-550/560 Nozzle cylindrical ø 17mm
TR-550/560 Nozzle conical ø 17mm

Universal adapter and Tweco tail

Fits all Translas standard MIG torches

Specifications

Universal adapter and Tweco tail
Fits all Translas standard MIG torches
