Fume Extraction Solutions

Flip up welding goggles

Specifications

HC Anti-scratch

AF Anti-fog

W5 Shade 5

Safety grinding goggles

Specifications

HC Anti-scratch

AF Anti-fog

Clear

Yellow

Grey

Specifications

Clear / Yellow / Grey lens

HC Anti-scratch

AF Anti-fog

Clear

Indoor/Outdoor lens

Yellow

Specifications

Clear / Yellow / Grey lens

HC Anti-scratch

AF Anti-fog

Clear

Yellow

Grey

Specifications

Clear / Yellow / Grey lens

HC Anti-scratch
AF Anti-fog

Clear

Yellow

Grey

Specifications

Clear / Yellow / Grey lens

HC Anti-scratch

AF Anti-fog

Goggles

Clear

Specifications

Clear lens

HC Anti-scratch

AF Anti-fog

T230

Specifications

Sizes 8-11

T240

Specifications

Sizes 7-11

T268

Specifications

Sizes 8,10,11

T269

Specifications

Sizes 8-11

T275

Specifications

Sizes 8-12

T480

Specifications

Sizes 8,10

T580

Specifications

Sizes 6-11

T88

Specifications

Sizes 8-11

Extended hood and leather coverage

Specifications

Extended Hood for Welding Helmet

Extended hood made out of durable flame-retardant cotton. It is suitable for overhead welding and helps on-site and field welders be protected against burns caused be welding spatter.

Can be ordered together or separately

Characteristics:

• Is Washable and durable
• Fits all FORCE welding helmets
• Has special stay-on rubber fit
• Blocks out ambient lights coming from behind the welder.

Force 300 Automatic welding helmet

Specifications

Force 300

• Optical class: 1 / 2 / 1 / 2;
• Viewing area 98x44mm (3.86″x1.73″)
• Cartridge size 110x90x9mm (4.33″x3.54″x0.35″)
• Arc sensor 2
• Light state DIN 3.5
• Dark state Variable Shade 9 ~ 13
• Shade control External, Variable Shade
• Power On/Off Automatic on/off
• Sensitivity control Low — High, by infinitely dial knob
• UV/IR Protection Up to Shade DIN16 at all times
• Power supply Solar cell. No battery change required
• Switching time 1/16.000s. from light to dark
• Dark to light 0.25 ~ 0.30s (fast) to 0.65 ~ 0.80s (slow) by infinitely dial knob
• Low amperage TIG rated ≥ 10 amps / DC; ≥ 10 amps / AC
• Grinding Yes
• Operating temperature -10°C~ +55°C (14°F ~ 131°F)
• Storing temperature -20°C~ +70°C (- 4°F ~ 158°F)
• Material helmet High Impact Resistance Nylon
• Total weight, with helmet 440g
• Application range Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Grinding;
• Approved DINplus, CE, ANSI Z87.1, CSA Z94.3, AS/NZS

Force 700 Automatic welding helmet

Specifications

Force 710S

• Optical class : 1 / 1 / 1 / 1
• Viewing area 97x47mm (3.82″x1.85″)
• Cartridge size 110x90x9mm (4.33″x3.54″x0.35″)
• Arc sensor 2
• Light state DIN 3.5
• Dark state Variable Shade 9 ~ 13
• Shade control Internal, Variable Shade
• Power On/Off Fully Automatic
• Sensitivity control Low — High, by infinitely dial knob
• UV/IR Protection Up to Shade DIN16 at all times
• Power supply Solar cell. Battery change required;1 x CR2450 lithium battery
• Switching time 1/25.000s. from light to dark
• Dark to light 0.1 ~ 1.0s by infinitely dial knob
• Low amperage TIG rated ≥ 2 amps / DC; ≥ 2 amps / AC
• Grinding Yes
• Operating temperature -10°C~ +55°C (14°F ~ 131°F)
• Storing temperature -20°C~ +70°C (- 4°F ~ 158°F)
• Material helmet High Impact Resistance Nylon
• Total weight, with helmet 440g
• Application range: Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Grinding
• Approved: CE, ANSI Z87.1, CSA Z94.3, AS/NZS

Force 730S

• Optical class: 1 / 1 / 1 / 2
• Viewing area 95x62mm (3.74″x2.44″)
• Cartridge size 110x90x9mm (4.33″x3.54″x0.35″)
• Arc sensor 4
• Light state DIN 3.5
• Dark state Variable Shade 5~ 8 / 9 ~ 13
• Shade control External, Variable Shade
• Power On/Off Fully Automatic
• Sensitivity control Low — High, by infinitely dial knob
• UV/IR Protection Up to Shade DIN16 at all times
• Power supply Solar cell. Battery change required;1 x CR2450 lithium battery
• Switching time 1/25.000s. from light to dark
• Dark to light 0.1 ~ 1.0s by infinitely dial knob
• Low amperage TIG rated ≥ 2 amps / DC; ≥ 2 amps / AC
• Grinding Yes
• Operating temperature -10°C~ +55°C (14°F ~ 131°F)
• Storing temperature -20°C~ +70°C (- 4°F ~ 158°F)
• Material helmet High Impact Resistance Nylon
• Total weight, with helmet 445g
• Application range: Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Oxyfuel Gas Welding (OFW); Oxygen Cutting (OC); Grinding
• Approved: CE, ANSI Z87.1, CSA Z94.3, AS/NZS

Force 800 Automatic welding helmet

Specifications

Force 820S:

• Optical class 1 / 1 / 1/ 1
• Viewing area 95x85mm (3.74″x3.35″)
• Cartridge size 133x114x9mm (5.24″x4.50″x0.35″)
• Arc sensor 4
• Light state DIN 3.5
• Dark state Variable Shade 6 ~ 9 / 9 ~ 13
• Shade control Internal, Variable Shade
• Power Automatic On / Off
• Sensitivity control Low — High, by infinitely dial knob
• UV/IR Protection Up to Shade DIN16 at all times
• Power supply “Solar cell. Battery change required; 1 x CR2450 lithium battery
• Switching time 1/25.000s. from light to dark
• Dark to light 0.1 ~ 1.0s by infinitely dial knob
• Oxyfuel gas welding Yes
• Oxygen cutting Yes
• Grinding Yes
• Low amperage TIG rated ≥ 2 amps / DC; ≥ 2 amps / AC
• Operating temperature -10°C~ +55°C (14°F ~ 131°F) *Suitable For High Temperature Welding
• Storing temperature -20°C~ +70°C (- 4°F ~ 158°F)
• Material helmet High Impact Resistance Nylon
• Total weight, with helmet 490g
• Application range Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Oxyfuel Gas Welding (OFW); Oxygen Cutting (OC); Grinding;
• Approved CE, ANSI Z87.1, CSA Z94.3, AS/NZS

Force 830S:

• Optical class 1 / 1 / 1/ 1
• Viewing area 97x62mm (3.82″x2.44″)
• Cartridge size 133x114x9mm (5.24″x4.50″x0.35″)
• Arc sensor 4
• Light state DIN 3.5
• Dark state Variable Shade 5~ 8 / 8 ~ 13
• Shade control Internal, Variable Shade;Digital Display Control
• Power Manual-on, Auto-off
• Sensitivity control Low — High, Digital Display Control
• UV/IR Protection Up to Shade DIN16 at all times
• Power supply Solar cell. Battery change required; 2 x CR2450 lithium battery
• Switching time 1/25.000s. from light to dark
• Dark to light 0.1 ~ 1.0s Digital Display Control
• Oxyfuel gas welding Yes
• Oxygen cutting Yes
• Grinding Yes
• Low amperage TIG rated ≥ 2 amps / DC; ≥ 2 amps / AC
• Operating temperature -10°C~ +55°C (14°F ~ 131°F) *Suitable For High Temperature Welding
• Storing temperature -20°C~ +70°C (- 4°F ~ 158°F)
• Material helmet High Impact Resistance Nylon
• Total weight, with helmet 490g
• Application range Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC); Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Oxyfuel Gas Welding (OFW); Oxygen Cutting (OC); Grinding;
• Approved CE, ANSI Z87.1, CSA Z94.3, AS/NZS

Force 900 Automatic Welding Helmet

With flip-up lens

Suitable for welding, grinding and cutting

Specifications Force 900 Welding Helmet

The automatic Force 900 welding helmet has the welder covered in every situation – welding, grinding and cutting.

ClearView

Cartridge is equipped with ClearView Technology, which provides you with an ultra-clear view during welding.

Digital Display Control

The Force 900 Digital Display Control has a clear interface design. You can switch between different modes within seconds. It also has a memory function which allows you to save the set parameters when switching between modes.

Multi-Functional Flip-UP Design

The Force 900 is a flip-up helmet with easy lift for grinding function, suiting welding/cutting/grinding mode. The transparent grinding lens is curved with a large view area of (20 x 12 cm). The welding lens with the highest optical glass -1/1/1/1- provides an exceptionally clear view of the arc during welding.

Technical Specifications Helmet

• • Optical Class: 1/1/1/1
  • Viewing Area: 107 x 75mm (4.21” x 2.95”)
  • Cartridge Size: 156 x 123 x 33 mm (6.14” x 4.84” x 1.30”)
  • Arc Sensor: 4
  • Grind state: DIN4
  • Light state: DIN4
  • Cutting shade: Shade No. from 5 to 8
  • Shade No. from 9 to 13
  • Shade Control: Internal, Digital Display Control
  • UV / IR Protection: Up to shade DIN13 at all times
  • Power Supply: Solar cell. Battery replaceable, 2x CR2450 lithium battery.
  • Switching Time: 1/25,000 s. from Light to Dark
  • Grinding: Yes
  • Delay (Dark to Light): 0.1 ~ +55°C (14 °F ~ 131 °F)

20 °C ~ +70 °C (-4 °F ~ 158 °F)

• Helmet Material: High Impact Resistance Nylon
• Total Weight: 765 grams
• Application Range: Stick Welding (SMAW); TIG DC∾ TIG Pulse DC; TIG Pulse AC; MIG/MAG/CO2; MIG/MAG Pulse; Plasma Arc Cutting (PAC) Plasma Arc Welding (PAW); Air Carbon Arc Cutting (CAC-A); Oxyfuel Gas Welding (OFW); Oxygen Cutting (OC); Grinding.
• Approved: DINplus, ANSI Z87.1, CSA Z94.3, AS/NZS 1338.1

PAPR Fresh air system

Specifications

Inhaled air 50 times cleaner than air in the immediate area

TH2 approved

Comfortable to wear

Unique design

Suitable for grinding and cutting

Easy to clean head cap

AirForce Fresh air set with flip-up helmet

Specifications

• Flip-up design
• Large view for grinding
• Auto-alarm system
• Rechargeable Li-ion battery
• Respiratory protection
• Intelligent air supply
• Real-time display indicator

P.N.: 570400

This product could be used in below field:

1- Isolating ward and medical observation site

2-Transfer of the infected

3-Corpse treatment

4-Environment disinfection

5-Sample collection

6-Laboratory testing

Ultrasonic seaming technology

Seamed with ultrasonic welding, with high-intensity feature and longer lifetime.

Multi-layer fabric

Lightweight specialized fabric. TM-H2 with a longer length to protect neck and shoulder.

Full view visual field

Large window size, curved design to better fit face-line, expanding the visual field.

Adjustable headgear

Adjustable headgear, with soft sweatband, improving the wearing comfort.

Leather apron

90 x 70 cm

Specifications

Leather apron

90 x 70 cm

Leather arm protectors (pair)

Specifications

Leather arm protectors (pair)

Leather jacket

Sizes L, XL

Specifications

Leather jacket

Sizes L, XL

Leather leg proctectors (pair)

Specifications

Leather leg proctectors (pair)

Leather pants

Size L

Specifications

Leather pants (without belt)

Size L

10XR Robotic 500 MIG Fume Extraction Gun – Water COOLED
MIXED GASES – 500 AMP, DUTY CYCLE – 100%

With the 10XR Robotic MIG Extraction Gun, harmful welding fumes can be safely and effectively extracted right at the source directly through the gun.

When the 10XR Robotic Welding Fumes Extractor is used with the ClearO2 W-Series 100 and 200, it allows for up to 98% of welding fume removal, which forms during the welding process. The fumes are extracted directly from the point of origin, through the nozzle before entering the atmosphere.

In addition to cleaner air, your employees will be able to work in a more pleasant environment.

By using the 10XR Robotic Welding Fumes Extractor, you have significantly less investment in alternative extraction options as it eliminates the requirement of a hood, curtain and larger powerful extraction systems being installed.

Experience significant savings with the 10XR with lower initial investment costs, lower operating costs and minimized maintenance costs including cleaning and filter life. Experience energy efficiencies compared to the current Industrial robot solutions that are available today.

8XC Cobot 400 MIG Fume Extraction – AIR COOLED
CO2 – 420 AMP, MIXED GASES – 400 AMP, DUTY CYCLE – 100%

The 8XC Cobot Fume Extractor reduces welding fume Up To 98% and has a unique contact tip for manual fitting and durability. Moreover, This cobot fume extractor gun designs a special contact tip for a longer lifetime. Also, we created two unique nozzles, 14mm and 17mm, for optimal performance and durability.

It is designed to be one of the most efficient fume extraction systems available in the welding industry. This torch is available at four different angles: 22°, 35°, 45°, and straight. When the 8XC Cobot MIG Fume Extractor is used with the ClearO2 W-series 100 and 200, it allows for up to 98% of welding fumes to be captured directly at the fume source. As a result, this Cobot 8XC MIG Fume Extractor is one of the safest and most effective welding fume extraction solutions available to ensure the safety of welding workers and for better working environments and working with the UR10e, UR5e, & UR16e Universal Robots.

HOW DOES IT WORK?
The 8XC MIG Fume Extractor is specifically designed for use by Cobots and Semi-Automated machines. There is a special design of nozzle on the 8XR and the combination of the unique design with the ClearO2 W-series, 100 and 200, provides the most effective results in the direct extraction of fumes from the source. In addition, the nickel-plated contact tips are designed to last a longer time than the other contact tips on the market. These tips are available for use with all kinds of wires and in different sizes. The 8X MIG Cobot fume extractor can use three types of Universal Robots: UR5e, UR10e, and UR16e.

To achieve the most outstanding results possible, the nozzle is unique in design. The openings, wall thickness, and size are all special to the nozzle. In addition, we have developed the grip ribs so that they perform optimally for optimal operation and superior performance.

8XC Cobot 500 MIG Fume Extraction Gun – Water COOLED
CO2 – 550 AMP, MIXED GASES – 500 AMP, DUTY CYCLE – 100%

The 8XC Cobot MIG Fume Extractor reduces welding fume Up To 98% and has a unique contact tip for manual fitting and durability. Moreover, This cobot fume extractor gun designs a special contact tip for a longer lifetime. Also, we created two unique nozzles, 14mm and 17mm, for optimal performance and durability.

It is designed to be one of the most efficient fume extraction systems available in the welding industry. This torch is available in four different angles: 22°, 35°, 45°, and straight. When the 8XC Cobot MIG Fume Extractor is used with the ClearO2 W-series 100 and 200, it allows for up to 98% of welding fumes to be captured directly at the fume source. As a result, this Cobot 8XC MIG Fume Extractor is one of the safest and most effective welding fume extraction solutions available to ensure the safety of welding workers and for better working environments and working with the UR10e, UR5e, & UR16e Universal Robots.

HOW DOES IT WORK?
The 8XC MIG Fume Extractor is specifically designed for use by Cobots and Semi-Automated machines. There is a special design of nozzle on the 8XC and the combination of the unique design with the ClearO2 W-series, 100 and 200, provides the most effective results in the direct extraction of fumes from the source. In addition, the nickel-plated contact tips are designed to last a longer time than the other contact tips on the market. These tips are available for use with all kinds of wires and in different sizes. The 8XC MIG Cobot fume extractor can use three types of Universal Robots: UR5e, UR10e, and UR16e.

To achieve the most outstanding results possible, the nozzle is unique in design. The openings, wall thickness, and size are all special to the nozzle. In addition, we have developed the grip ribs so that they perform optimally for optimal operation and superior performance.

8XC Cobot 500 MIG Fume Extraction Gun – Water COOLED
CO2 – 550 AMP, MIXED GASES – 500 AMP, DUTY CYCLE – 100%

The 8XC Cobot Fume Extractor reduces welding fume Up To 98% and has a unique contact tip for manual fitting and durability. Moreover, This cobot fume extractor gun designs a special contact tip for a longer lifetime. Also, we created two unique nozzles, 14mm and 17mm, for optimal performance and durability.

It is designed to be one of the most efficient fume extraction systems available in the welding industry. This torch is available in four different angles: 22°, 35°, 45°, and straight. When the 8XC Cobot MIG Fume Extractor is used with the ClearO2 W-series 100 and 200, it allows for up to 98% of welding fumes to be captured directly at the fume source. As a result, this Cobot 8XC MIG Fume Extractor is one of the safest and most effective welding fume extraction solutions available to ensure the safety of welding workers and for better working environments and working with the UR10e, UR5e, & UR16e Universal Robots.

HOW DOES IT WORK?
The 8XC MIG Fume Extractor is specifically designed for use by Cobots and Semi-Automated machines. There is a special design of nozzle on the 8XC and the combination of the unique design with the ClearO2 W-series, 100 and 200, provides the most effective results in the direct extraction of fumes from the source. In addition, the nickel-plated contact tips are designed to last a longer time than the other contact tips on the market. These tips are available for use with all kinds of wires and in different sizes. The 8XC MIG Cobot fume extractor can use three types of Universal Robots: UR5e, UR10e, and UR16e.

To achieve the most outstanding results possible, the nozzle is unique in design. The openings, wall thickness, and size are all special to the nozzle. In addition, we have developed the grip ribs so that they perform optimally for optimal operation and superior performance.

8XC MINI Cobot 250 MIG Fume Extraction Gun – AIR COOLED
CO2 – 280 AMP, MIXED GASES – 250 AMP, DUTY CYCLE – 100%

The 8XC Cobot Fume Extractor reduces welding fume Up To 98% and has a unique contact tip for manual fitting and durability. Moreover, This cobot fume extractor gun designs a special contact tip for a longer lifetime. Also, we created two unique nozzles, 14mm and 17mm, for optimal performance and durability.

It is designed to be one of the most efficient fume extraction systems available in the welding industry. This torch is available in four different angles: 22°, 35°, 45°, and straight. When the 8XC Cobot MIG Fume Extractor is used with the ClearO2 W-series 100 and 200, it allows for up to 98% of welding fumes to be captured directly at the fume source. As a result, this Cobot 8XC MIG Fume Extractor is one of the safest and most effective welding fume extraction solutions available to ensure the safety of welding workers and for better working environments and working with the UR10e, UR5e, & UR16e Universal Robots.

HOW DOES IT WORK?
The 8XC MIG Fume Extractor is specifically designed for use by Cobots and Semi-Automated machines. There is a special design of nozzle on the 8XR and the combination of the unique design with the ClearO2 W-series, 100 and 200, provides the most effective results in the direct extraction of fumes from the source. In addition, the nickel-plated contact tips are designed to last a longer time than the other contact tips on the market. These tips are available for use with all kinds of wires and in different sizes. The 8XC MIG Cobot fume extractor can use three types of Universal Robots: UR5e, UR10e, and UR16e.

To achieve the most outstanding results possible, the nozzle is unique in design. The openings, wall thickness, and size are all special to the nozzle. In addition, we have developed the grip ribs so that they perform optimally for optimal operation and superior performance.

Air flow meter Extractor

Gas flow meter Extractor

Brush

Multitool

Ceramic spray

Fume extraction torch
Light weight – only 1,1 kg
CO2 – 280 Amp
250 Amp Mixed gases
100% Duty cycle
Air cooled
Specifications

• Integrated extraction on the gas nozzle
• Lightest torch currently on the market – Only 1,1 kg
• Metal neck
• Flexible and maneuverable hose with ball-socket joint
• Small, ergonomic handle
• 90-95% fume extraction
• 3 interchangeable nozzles for various applications
• Especially designed for welding jobs where constant changing in positions is required, such as in automotive welding

Fume extraction welding torch gun with flexible hose

CO2 – 320 Amp

300 Amp Mixed gases

100% Duty cycle

Air cooled

Specifications

• Fume extraction at the source
• Extra flexible hose
• Ergonomic handle
• For heavy-duty applications
• 3 interchangeable nozzles for various applications
• 90-95% fume extraction
• 45° bent metal neck for sturdier look and feel on the job

Fume extraction welding torch gun with flexible hose

CO2 – 550 Amp

500 Amp Mixed gases

100% Duty Cycle

Water cooled

Specifications

• Fume extraction at the source
• Extra flexible hose
• Ergonomic handle
• For heavy-duty applications
• 90-95% fume extraction
• 3 interchangeable nozzles for various applications
• 45° bent metal neck

8TE-17 TIG EXTRACTOR- Air COOLED
DC – 140 AMP, AC/DC – 100 AMP, DUTY CYCLE – 35%

Specifications:
Reduces Welding Fume Up To 95%.
Same convenient handle as regular 8XT gun.
Various switch modules are available.
Extreme Flexible hose on the first meter.
Standard TIG consumables.

The 8TE TIG Fume Extractors protect the welders and other workers in the factory from harmful fumes
and metals like Aluminium, Chromium, Iron, Manganese, and Nickel which are possibly released during the welding process.

8TE-35 TIG EXTRACTOR- Water Cooled
DC – 320 Amp, AC/DC – 230 AMP, DUTY CYCLE – 100%

Specifications:
Reduces Welding Fume Up To 95%.
Same convenient handle as a regular 8XT gun.
Various switch modules are available.
Extreme Flexible hose on the first meter.
Standard TIG consumables.

The 8TE TIG Fume Extractors protect the welders and other workers in the factory from harmful fumes
and metals like Aluminium, Chromium, Iron, Manganese, and Nickel which are possibly released during the welding process.

8TE-30 TIG EXTRACTOR – Water COOLED
DC – 320 AMP, AC/DC – 330 AMP, DUTY CYCLE – 100%

Specifications:
Reduces Welding Fume Up To 95%.
Same convenient handle as regular 8XT gun.
Various switch modules are available.
Extreme Flexible hose on the first meter.
Standard TIG consumables.

The 8TE TIG Extractors protect the welders and other workers in the factory from harmful fumes
and metals like Aluminium, Chromium, Iron, Manganese, and Nickel which are possibly released during the welding process.

The Translas 8XE MINI 200 is the lightest MIG fume extraction gun on the market only 2.4 lb.

8XE MINI 200 MIG Fume Extraction Gun Air Cooled
CO2 – 230 AMP, MIXED GASES – 200 AMP, DUTY CYCLE – 100%
Weight*: 2.4 lb

The 8XE MINI 200 MIG fume extraction gun integrates the most efficient fume extraction structure in the welding industry. The gun comes with three different angles, 30°, 45°, and straight. The 8XE 200 MINI MIG Extractor, combined with the ClearO2 W-series 100 and 200, captures up to 98% of welding fumes directly at the source. It provides the safest and most effective solution for welders and workers to breathe CLEAN AIR and enjoy better work environments.

Specifications:
Reduces Welding Fume Up To 98%
Unique contact tip for manual fitting and durability.
Special design contact tip for a longer lifetime.
Ergonomic ball socket 30° angle and 360° rotatable.
Two unique nozzle designs 12mm and 14mm for optimal performance and durability

* The gun’s weight is measured 3’ above the ground

8XE MIG 400 Fume Extraction Gun – AIR-COOLED
CO2 – 420 AMP, MIXED GASES – 400 AMP, DUTY CYCLE – 100%
Weight*: 3.28 lb

The 8XE 400 MIG fume extraction gun integrates the most efficient fume extraction structure in the welding industry. The gun comes with three different angles, 30°, 45°, and straight. The 8XE 400 MIG Extractor, combined with the ClearO2 W-series 100 and 200, captures up to 98% of welding fumes directly at the source. It provides the safest and most effective solution for welders and workers to breathe CLEAN AIR and enjoy better work environments.

Specifications:
Reduces Welding Fume Up To 98%
Unique contact tip for manual fitting and durability.
Special design contact tip for a longer lifetime.
Ergonomic ball socket 30° angle and 360° rotatable.
Two unique nozzle designs 14mm and 17mm for optimal performance and durability

* The gun’s weight is measured 3’ above the ground.

8XE MINI 250 MIG Fume Extraction Gun – AIR COOLED
CO2 – 280 AMP, MIXED GASES – 250 AMP, DUTY CYCLE – 100%
Weight*: 2.9 lb

The 8XE MINI 250 MIG fume extraction gun integrates the most efficient fume extraction structure in the welding industry. The gun comes with three different angles, 30°, 45°, and straight. The 8XE 250 MINI MIG Extractor, combined with the ClearO2 W-series 100 and 200, captures up to 98% of welding fumes directly at the source. It provides the safest and most effective solution for welders and workers to breathe CLEAN AIR and enjoy better work environments.

Specifications:
Reduces Welding Fume Up To 98%
Unique contact tip for manual fitting and durability.
Special design contact tip for a longer lifetime.
Ergonomic ball socket 30° angle and 360° rotatable.
Two unique nozzle designs 14mm and 17mm for optimal performance and durability

* The gun’s weight is measured 3’ above the ground.

8XE MIG 500 Fume Extraction Gun – Water COOLED
CO2 – 500 AMP, MIXED GASES – 500 AMP, DUTY CYCLE – 100%
Weight*: 3.7 lb

The 8XE 500 MIG fume extraction gun integrates the most efficient fume extraction structure in the welding industry. The gun comes with three different angles, 30°, 45°, and straight. The 8XE 500 MIG Extractor, combined with the ClearO2 W-series 100 and 200, captures up to 98% of welding fumes directly at the source. It provides the safest and most effective solution for welders and workers to breathe CLEAN AIR and enjoy better work environments.

Specifications:
Reduces Welding Fume Up To 98%
Unique contact tip for manual fitting and durability.
Special design contact tip for a longer lifetime.
Ergonomic ball socket 30° angle and 360° rotatable.
Two unique nozzle designs 14mm and 17mm for optimal performance and durability

* The gun’s weight is measured 3’ above the ground.

HIGH-PERFORMANCE CENTRAL VACUUM SYSTEMS

Translas has a complete range of central high vacuum fume extraction
systems ranging from 5HP to 75HP units which will handle 5 to 40+
technicians using welding guns at the same time.

KEY BENEFITS:
• Ideal for production shops with 5 to 40+ users welding at the same time.
• 10 to a twin 75HP centrifugal multi-stage pump units can be set at various
vacuum levels from 5” HG
(68” water column) for short pipe runs to 10” HG (135” water column) to
offset friction losses on long pipe runs.
• Large aluminum impellers and fabricated housings result in a vacuum
pump that is far more efficient than competitive products (which
typically have smaller steel impellers and sections held together with
tie-rods).
• Comes equipped with cartridge filters, automatically compressed air pulse
jet cleaning, and primary cyclonic separation.
• Our industrial-grade induction motors have a 20,000+ hours rating.
• Captures dangerous welding fumes before they enter the welder’s
breathing zone.
• Ideal for MIG, TIG, arc, and robotic welding.
• No lost production time moving large fume extraction arms every time
the welder changes position.
• Source capture welding gun at 100 CFM or welding attachments only
require 80 CFM; eliminating the need for costly air makeup
systems required with high volume systems.
• Several filter options are available, including combination cyclone
separator and polyester cartridge filters with automatic pulse jet
cleaning.

The ClearO2 Giant Portable unit is available with a power supply of 208-240, 460 & 575 volts

GIANT PORTABLE FUME EXTRACTOR

Translas’s portable fume extractor “Giant” is designed to capture and
filter dry impurities created during welding, grinding and the cutting of
metals.
• Meets OSHA air quality standards and increases health and safety
standards by minimizing hazards that cause respiratory ailments
• Available with two arm options: 1 x 8-inch arm or 2 x 6-inch arms.
Self-supporting joints and flexible hoses for easy placement with
smooth bore tubing for unimpeded air movement.
• 1200 CFM at hood for powerful performance.
• Excellent three-stage filtration: aluminum mesh pre-filter, second
polyester cartridge filters and final carbon after the filter. Manual pulse
jet cleaning comes standard and an optional HEPA upgrade available.
• Unit reduces facility maintenance costs by eliminating smoke and
dust before particles to settle on equipment and work surfaces

The ClearO2 Rollout Portable unit is available with a power supply of 115 volts

ROLLOUT PORTABLE MOBILE WELDING FUME EXTRACTION UNIT

Translas’s Rollout portable welding fume extraction system is designed to capture and
filter dry impurities created during welding, grinding and the cutting of
metals.
• Meets OSHA air quality standards and increases health and safety
standards by minimizing hazards that cause respiratory ailments.
• Standard arm measures 6” in diameter and fully extends to 10-
feet. Other sizes are also available on request.
• 700 CFM at hood for powerful performance.
• Excellent three-stage filtration: aluminum mesh pre-filter, second
polyester cartridge filters and final carbon after the filter. Manual pulse
jet cleaning comes standard and an optional HEPA upgrade available.
• Unit reduces facility maintenance costs by eliminating smoke and
dust before particles to settle on equipment and work surfaces.

The ClearO2 T100 unit is available with a power supply of 220V-240V (T100)  and CSA and CE certified. W3 Under construction.

Specifications

The ClearO2 T100 is designed to accompany the 8TE TIG Extractor from Translas. With the combination of the 8TE TIG Extractor range of welding fume torch and ClearO2 T100 unit we capture between 90% and 95% of welding fume at the source and filter these with efficiency > IFA 99.8%. The compact unit is perfect for changing location on the job due to its lightweight – only 30 kg – and its four wheels with two lockable.

Automatic Cleaning

The ClearO2 T100 unit has an automatic cleaning function by reverse compressed air pulse. The moment the under pressure in the filter is too high, the unit starts to clean the filter automatically. A manual cleaning function can be done by pressing a single button. The automatic Start/Stop function to preserve energy and to synchronize the unit with the 8TE TIG Extractor is a standard on the ClearO2 units. The moment the torch is out of the specially designed torch holder option, the machine automatically starts working.

Light and Mobile

The ClearO2 T100 unit is designed to serve the needs of a single welder, who needs to change their work-place.

The ClearO2 T200 unit is available with a power supply of 220V-240V (T200) and CE and W3 certified.

Specifications

The ClearO2 T200 is designed to accompany the 8TE TIG Extractor from Translas. With the combination of the 8TE TIG Extractors range of welding fume torches and ClearO2 T200 unit we capture between 90% and 95% of welding fume at the source and filter these with efficiency > IFA 99.8%. The compact unit is perfect for changing location on the job due to its lightweight – only 45 kg – and its four wheels with two lockable.

Automatic Cleaning

The ClearO2 T200 unit has an automatic cleaning function by reverse compressed air pulse. The moment the under pressure in the filter is too high, the unit starts to clean the filter automatically. A manual cleaning function can be done by pressing a single button. The automatic Start/Stop function to preserve energy and to synchronize the unit with the 8TE TIG Extractor is a standard on the ClearO2 units. The moment the torch is out of the specially designed torch holder option, the machine automatically starts working.

Continuous rated motor

The electric motor of the unit is designed to work continuously without losing its power. Due to the automatic cleaning function and the simplified motor system, the maintenance of the unit is minimal, making it long-lasting and time-saving. With a filter area of 5m², this is one of the most efficient units of its size with the largest filter. The filter is disposable and has an active surface with an efficiency: IFA >99,8%.

Light and Mobile

The ClearO2 T200 unit is designed to serve the needs of two welders, who need to change their work-place. Examples for such applications are in shipbuilding, wind tower building, tank construction and other similar fabrication industries. The four wheels with two locks and the lightweight – only 45kg – let the welder move the unit with ease to the next working location.

ClearO2 Two-welder mobile filtration unit

Designed for the 7XE Extractor torch

Exceptional filter efficiency IFA >99.8%

Specifications

The ClearO2 W200 is designed to accompany the 8XE MIG and 8XR MIG Cobot Extractors from Translas. With the combination of the 8XE MIG and 8XR MIG Cobot Extractors range of welding fume torches and ClearO2 W200 units, we capture between 90% and 98% of welding fume at the source and filter these with efficiency > IFA 99.8%. The compact unit is perfect for changing location on the job due to its lightweight – only 58 kg – and its four wheels with two lockable.

Automatic Unit

The ClearO2 W200 unit has an automatic cleaning function by reverse compressed air pulse. The moment the pressure in the filter is too high, the unit starts to clean the filter automatically. A manual cleaning function can be done by pressing a single button. The automatic start/stop function to preserve energy and to synchronize the unit with the 8XE MIG and 8XR MIG Cobot Extractors is a standard on the ClearO2 units. The moment the gun is out of the specially designed torch holder, the machine automatically starts working. The gun holder is designed to work only with the 8XE MIG and 8XR MIG Cobot Extractors

Continuous Rated Motor

The electric motor of the unit is designed to work continuously without losing power. Maintenance on the unit is minimal due to the automatic cleaning function and the simplified motor system, making it long-lasting and time-saving. With a filter area of 5m², this is one of the most efficient units of its size with the largest filter. The filter is disposable and has an active surface with an efficiency: IFA >99,8%.

Light And Mobile

The ClearO2 W200 unit is designed to serve the needs of a welder, who needs to move around their workplace. Examples of such applications are in shipbuilding, wind tower building, tank construction and other similar fabrication industries. The four wheels with two locks and the lightweight – only 58kg – allow the welder to move the unit with ease to the next working location.

The ClearO2 unit is available with a power supply of 220V-240V (W100) or 380-480V (W150) and CE and W3 certified.

Specifications

The ClearO2 W100/ W150 is designed to accompany the 8XE MIG and 8XR MIG Cobot Extractors from Translas. With the combination of the 8XE MIG and 8XR MIG Cobot Extractors range of welding fume torches and ClearO2 W100/150 units, we capture between 90% and 98% of welding fume at the source and filter these with efficiency > IFA 99.8%. The compact unit is perfect for changing location on the job due to its lightweight – only 45 kg – and its four wheels with two lockable.

Automatic Cleaning

The ClearO2 W100/ W150 unit has an automatic cleaning function by reverse compressed air pulse. The moment the under pressure in the filter is too high, the unit starts to clean the filter automatically. A manual cleaning function can be done by pressing a single button. The automatic Start/Stop function to preserve energy and to synchronize the unit with the 8XE MIG and 8XR MIG Cobot Extractors is a standard on the ClearO2 units. The moment the gun is out of the specially designed torch holder option, the machine automatically starts working.

Continuous rated motor

The electric motor of the unit is designed to work continuously without losing its power. Due to the automatic cleaning function and the simplified motor system, the maintenance of the unit is minimal, making it long-lasting and time-saving. With a filter area of 5m², this is one of the most efficient units of its size with the largest filter. The filter is disposable and has an active surface with an efficiency: IFA >99,8%.

Light and Mobile

The ClearO2 W100/ W150 units are designed to serve the needs of a single welder, who needs to change their workplace. Examples of such applications are in shipbuilding, wind tower building, tank construction and other similar fabrication industries. The four wheels with two locks and the lightweight – only 45kg – let the welder move the unit with ease to the next working location.

Ball valve to reduce the suction flow

Coupler for suction hose black tbv Ø51mm unit side

Coupler to extend the suction hose Ø51mm

Extension cable auto start/stop 5-p plug W-serie

Specifications

• Extension cable auto start/stop 3mtr incl. 5-p plug W-serie
• Extension cable auto start/stop 5mtr incl. 5-p plug W-serie
• Extension cable auto start/stop 3mtr incl. 10-p plug W-serie

Filter W-serie ClearO2

Specifications

• Filter W-serie ClearO2 5m2

Filtermat W-serie ClearO2

Specifications

• Filtermat W-serie ClearO2 (set/5pc)

Pressure reducing valve 5-15bar 1/4-NP7.2

Sensing cable auto start/stop 4mtr W-serie

Specifications

• Sensing cable auto start/stop 4mtr W-serie

Suction hose for the ClearO2

Specifications

• ClearO2 suction hose black Ø51m 5mtr
• ClearO2 suction hose black Ø51m 10mtr

Torch holder for automatic start/stop

Specifications

• Torch holder Ø40mm for automatic start/stop 5mtr ClearO2
• Torch holder Ø40mm for automatic start/stop 10mtr ClearO2
• Torch holder Ø50mm for automatic start/stop 5mtr ClearO2
• Torch holder Ø55mm for automatic start/stop 10mtr ClearO2
